First, an overview
The three networks with sludge dewatering machine is our company introduction, digestion and absorption of the United States Jimmy Wang advanced technology to develop and produce the latest generation of patented dewatering equipment, it handles large capacity, high efficiency, dehydration (into the plasma concentration of 2-5% can be directly to 30-35%), low energy consumption (tons of power consumption is not higher than 3KW, only the double helix to squeeze the advantages of pulp, 1/10), it not only solved the ordinary dual-network filter press dewatering raw materials appears to run material, but also solve the problem of small network at both ends of material pressure, and a simple structure, easy installation, is the ideal product of the extraction of black liquor or slurry concentrate.
Second, the principle
Based on the difference of the dehydration zone pressure, the entire dehydration process of the wire part can be divided into pre-dehydration zone, pressure dewatering zone and pressure forced dehydration District.
Slurry cloth pulp evenly distributed on the Internet pre-dehydration zone into the gravity dehydration. Take off most of the water slurry in the region by its own gravity, so that the slurry lost fluidity. In the network driven by the slurry into the Chinese and the net formation of wedge-shaped intersection area, the pressure dehydration. Slurry in the region by the next filter's mild extrusion, dehydration to about 90%, and then into the pressure dewatering zone. Roller pressure dewatering area consists of eight different diameter dehydration District are holes roller rapid dehydration in the extrusion process on both sides of the filter. Dehydration pressure roller diameter gradually small arrangement and the change of filter corners, to ensure the formation of dehydration increasing pressure and the corresponding shear force, so that the pulp repeatedly in the "S" shape dehydration District deformation and off constantly In addition to the water to a certain dryness to form a slurry cake, scraped off by the scraper. Shed a slurry of the filter into the next work cycle after the high-pressure water wash clean.
Third, the technical parameters
The three networks with sludge dewatering machine is our company introduction, digestion and absorption of the United States Jimmy Wang advanced technology to develop and produce the latest generation of patented dewatering equipment, it handles large capacity, high efficiency, dehydration (into the plasma concentration of 2-5% can be directly to 30-35%), low energy consumption (tons of power consumption is not higher than 3KW, only the double helix to squeeze the advantages of pulp, 1/10), it not only solved the ordinary dual-network filter press dewatering raw materials appears to run material, but also solve the problem of small network at both ends of material pressure, and a simple structure, easy installation, is the ideal product of the extraction of black liquor or slurry concentrate.
Second, the principle
Based on the difference of the dehydration zone pressure, the entire dehydration process of the wire part can be divided into pre-dehydration zone, pressure dewatering zone and pressure forced dehydration District.
Slurry cloth pulp evenly distributed on the Internet pre-dehydration zone into the gravity dehydration. Take off most of the water slurry in the region by its own gravity, so that the slurry lost fluidity. In the network driven by the slurry into the Chinese and the net formation of wedge-shaped intersection area, the pressure dehydration. Slurry in the region by the next filter's mild extrusion, dehydration to about 90%, and then into the pressure dewatering zone. Roller pressure dewatering area consists of eight different diameter dehydration District are holes roller rapid dehydration in the extrusion process on both sides of the filter. Dehydration pressure roller diameter gradually small arrangement and the change of filter corners, to ensure the formation of dehydration increasing pressure and the corresponding shear force, so that the pulp repeatedly in the "S" shape dehydration District deformation and off constantly In addition to the water to a certain dryness to form a slurry cake, scraped off by the scraper. Shed a slurry of the filter into the next work cycle after the high-pressure water wash clean.
Third, the technical parameters
|
型 号 |
DT1000
|
DT1500
|
DT2000
|
DT3000
|
|
|
功率KW
|
传动电机
|
0.75
|
1.5
|
1.5
|
2.2
|
|
压缩空气
|
0.75
|
0.75
|
0.75
|
0.75
|
|
|
带宽
|
1000
|
1500
|
2000
|
3000
|
|
|
处理量(m3/h)
|
3-4
|
4-6
|
6-8
|
9-12
|
|
|
进浆浓度
|
8-12%
|
||||
|
出浆浓度
|
30-40%
|
||||
