CXS series of multi-layer pressure screen within a single device to a multi-level screening, slurry two to three screening in the same device can be realized, which greatly simplify the pulping process, reducing the slurry tank, pumpsettings, and pipe not only reduces the cost of investment in equipment, but also reduces the power consumption of the tons of pulp, the device power consumption is 45-65% of the traditional up-flow pressure screen.
|
型号
|
筛孔尺寸(mm)
|
筛缝尺寸(mm)
|
进浆浓度（%）
|
生产能力(t/d)
|
电机功率(kw)
|
|
CXS50
|
ø1-ø5
|
H0.1-H1
|
0.1-4
|
13-25
|
5.5-11
|
|
CXS100
|
ø1-ø5
|
H0.1-H1
|
0.1-4
|
25-50
|
11-22
|
|
CXS200
|
ø1-ø5
|
H0.1-H1
|
0.1-4
|
50-100
|
22-45
|
|
CXS300
|
ø1-ø5
|
H0.1-H1
|
0.1-4
|
70-135
|
30-55
|
|
CXS400
|
ø1-ø5
|
H0.1-H1
|
0.1-4
|
100-200
|
45-90
|
|
CXS500
|
ø1-ø5
|
H0.1-H1
|
0.1-4
|
140-270
|
55-110
|
|
CXS600
|
ø1-ø5
|
H0.1-H1
|
0.1-4
|
170-335
|
75-160
|
|
CXS700
|
ø1-ø5
|
H0.1-H1
|
0.1-4
|
210-420
|
90-180
|
|
CXS800
|
ø1-ø5
|
H0.1-H1
|
0.1-4
|
250-500
|
110-220
|
