CSG dual-drum pulse low net anterior ethmoid, the outflow of the structure of the double drum sieve, configure the adjustable gap, high-precision inner and outer rotor, the rotor shape and arrangement type compatible with the advanced corrugated drum sieve, can take to improvepressure screen through the ability to significantly reduce power consumption and a plasma pulse, a high efficiency and low consumption of the net sieve
|
型号
|
CSG10
|
CSG20
|
CSG30
|
CSG40
|
CSG50
|
CSG60
|
|
筛选面积(m²)
|
0.6
|
1.0
|
1.5
|
2.0
|
2.5
|
3.0
|
|
进浆压力(MPa)
|
0.1-0.3MPa
|
|||||
|
进浆浓度（%）
|
0.3-1.2%
|
|||||
|
通过量(L/SEC)
|
7
|
12
|
18
|
24
|
30
|
36
|
|
生产能力(t/d)
|
60
|
100
|
150
|
200
|
250
|
300
|
|
电机功率(kw)
|
7.5
|
11-15
|
15-18.5
|
22-30
|
30-37
|
45
|
|
外形尺寸(mm)
|
1800×850×1350
|
2000×1000×1000
|
2200×1150×1800
|
2500×1250×2000
|
2700×1400×2200
|
2900×1550×2400
|
