The machine is key equipment for recycled paper production process, the distributed processing of waste paper pulp. Its working principle is forced into a slurry with high concentration of state disperser, heated by steam at the same time, was strongly of rubbing between the fixed disk and dynamic disk with a special tooth, so that the material of viscose fiber, paraffin , plastics, rubber, asphalt, inks, hot melt impurities dissolved scattered loss of viscosity, or dispersed into the extent to facilitate the visual observation of the next process to remove or people, to the lifting of such impurities brought papermaking obstacles, improve into the paper the appearance of quality, improve product quality.
Disc disperser generally oblique spiral concentrator, the double helix squeeze pulp, spiral heaters, feed screw together to form a complete set of recycled pulp heat dispersion systems. Is the essential step of the process configuration for the production of high-grade recycled paper.
Disc disperser generally oblique spiral concentrator, the double helix squeeze pulp, spiral heaters, feed screw together to form a complete set of recycled pulp heat dispersion systems. Is the essential step of the process configuration for the production of high-grade recycled paper.
|
型 号
|
CXP550
|
CXP650
|
CXP800
|
|
|
生产能力 t/d
|
40-60
|
60-80
|
80-100
|
|
|
进浆浓度 ％
|
25-40
|
|||
|
热分散温度 ℃
|
90-100
|
|||
|
公称直径 mm
|
Φ550
|
Φ650
|
Φ800
|
|
|
配用电机
|
Y315M-4/132KW
|
Y315M1-4/185KW
|
Y315M2-4/220KW
|
|
|
螺旋预
热器
|
公称直径mm
|
Φ600
|
Φ700
|
Φ800
|
|
配用电机
|
Y132S-4/5.5KW
|
Y132M-4/7.5KW
|
Y160M-4/11KW
|
|
|
螺旋转速r/min
|
16.5
|
|||
|
分散机进料螺旋
|
公称直径mm
|
Φ300
|
Φ400
|
Φ500
|
|
配用电机
|
Y112M-4/4KW
|
Y132S-4/5.5KW
|
Y132M-4/7.5KW
|
|
