ZGPT high consistency bleaching tower is used for wood pulp and other pulp species of high concentration slurry (28% -32%) hydrogen peroxide bleaching reaction device, pulp and bleaching liquid by the high concentration of the mixer after mixing into the bleachdistributor tower, pulp bleaching tower at the top of the falls from the top of the tower required after two hours, from the bottom of the spiral discharging device to discharge into the storage slurry tank, slurry from the top to the bottom to complete the entire high concentration peroxidehydrogen bleaching process. The device uses a cone structure, in order to reduce the possibility of slurry bridge, tower equipped with a slurry distribution, in order to reduce the slurry of the natural angle of repose; bottom using the pitch, such as diameter, variable mandrel shaft diameter the feed screw to ensure that the slurry evenly on the tower each contour cross section whereabouts in order to ensure a high concentration hydrogen peroxide bleaching process remain basically the same requirements for each part of the tower slurry residence time. This equipment has advanced structure, reliable, production capacity, the bleaching effect, craft and wide adaptability, easy operation and maintenance characteristics.
Product Specification :20-80m3
Product Specification :20-80m3
|
型号
参数
|
ZGPT10
|
ZGPT20
|
ZGPT30
|
|
公称容积M3
|
10
|
20
|
40
|
|
生产能力T/D
|
15-20
|
50-70
|
100-140
|
|
漂白浓度％
|
20-32
|
28-32
|
28-32
|
|
漂白温度℃
|
65-70
|
65-70
|
65-70
|
|
漂白时间h
|
1.5-2
|
2-3
|
2-3
|
|
进浆口mm
|
200×130
|
200×130
|
200×130
|
|
出浆口mm
|
1224×530
|
1680×632
|
2235×632
|
|
排气口mm
|
Dgl00
|
Dg100
|
Dgl00
|
|
配用动力
|
YCTl80-4A/4kw
|
YCT200-4A/5.5kw
|
YCT200-4B/7.5kw
|
|
外形尺寸mm
(长×宽×高)
|
4880×2010×4740
|
5860×2260×5750
|
6420×2680×7100
|
|
设备净重kg
|
3500
|
5500
|
10500
|
|
工作重量kg
|
15000
|
25000
|
35000
|
