The equipment is mainly used for the separation of the length of the fiber slurry, in order to cost-effectively dealt with separately and use. Slurry along the tangent to a certain pressure into the sieve drum under the action of external pressure and rotor, short fibers through the screen drum discharged by the export of staple fiber, long fiber rose to the export of long-fiber discharge. Up-flow structure, the heavy impurities in the bottom of heavy slag slag port discharge, reducing the wear and tear of the sieve drum and the drum. Drum using convex desktop organizations can better ensure that the height of the drum on the fiber through the sieve slit speed, with a screening at high concentrations, the production capacity of fiber grading effect, low energy consumption.
The main parameters
|
型号
|
ZSL63
|
ZSL64
|
ZSL65
|
|
筛鼓面积m2
|
1.2
|
2
|
3
|
|
处理浓度%
|
|
1.5-2.5
|
|
|
处理能力t/d
|
110-280
|
170-410
|
250-620
|
|
进浆压力MPa
|
|
0.15-0.35
|
|
|
电机功率kw
|
75-90
|
90-132
|
160-200
|
|
外形尺寸（长x宽x高H）mm
|
2490x1400x2130
|
2570x1425x2500
|
3500x1650x2530
|
