First, an overview
The series of automatic river water purifier, the integration of automatic river purification Set reaction, flocculation, sedimentation, set of mud, mud, water harvesting, water distribution, filtration, backwash, sewage and other running process the essence of one; with no personnel to operate achieve monomer automatic ability to run the water plant automation management water purification unit. Water purification plants (stations) to become a complete set of Autorun.
This series of water purification devices for integrated structure; applies not only to a wide range of treatment effect, the stability of the water quality, and water consumption, the kinetic energy consumption province, small footprint, no secondary pollution equipment to purify water. Is the integration of energy-efficient water purification of water and energy saving, saving labor, saving the project site, may merge with the clear water tank construction, and do not need to backwash the pool and auxiliary pump facilities to handle new products. Especially suitable for efficient water use areas.
Second, the performance parameters
1, applies to the raw water turbidity: ≤ 1000NTU
2, for the raw water temperature: room temperature
3, water purification water turbidity: ≤ 10NTU
4, a water effluent color: ≤ 15 (water chrominance shall not exceed 25)
5, precipitation surface load: 4.3 m3 / h? M2
6, filter design filtration rate: of 10 m / h
7, filter backwashing strength: 15 ~ 18l / s? M2 (adjustable)
8, rinse lasted: t = 1 ~ 5min (adjustable)
9, the total residence time: T total = 60 ~~ was 65 minutes
10, the device inlet pressure: ≥ 0.09MPa
Third, the performance benefits
A series of water purification equipment from the anti-reaction, flocculation and sedimentation, water harvesting, water distribution, filtering, body wash, mud run the program are to achieve the effect of the automatic operation of a central control cabinet left PLC1, on duty as long as the timing for water quality monitoring, operation and management do not need a water purification device.
2, high concentrations of flocculation layer, make the original impurities in the water particles in the meantime get full contact with the collision probability of adsorption increases, and thus can adapt to a variety of raw water temperature and turbidity, high removal efficiency of impurity particles.
3, rapid sludge concentration chamber and adjustable automatic sludge discharge system, to ensure the excess sludge is immediately removed, thus ensuring a stable impurity particle removal.
4, efficient flocculation and sedimentation effects, precipitation water quality has been maintained in good condition.
Catchment head of the catchment system and the most novel and original, so that catchment more uniform and effective, not only to improve the volume utilization factor, and the head of a very small catchment.
6, water purification systems automation, both to ensure the efficient filtering of the water purification system (in the raw water turbidity of less than 3000mg / l, the turbidity of the water after the filter can be maintained at about 3mg / l), but also automatically recoil without additional set the backwash pump or air compressor and other electrical equipment, but also save a lot of investment in infrastructure and day-to-day operation, maintenance, maintenance costs.
7, the device since the water is low about 3%, save valuable water resources play an active role.
8, small footprint, compared with the normal water structure, can save more than accounted for 50% of the ground, the height of about 2.9 m, both indoor and outdoor placement.
9, to facilitate the expansion, alteration, relocation, or ex situ and then.
10, infrastructure and short duration, for a quarter of the construction cycle of conventional clarification and filtration facilities.
11, the export of clean water height ≥ 2m, clear water tank can be built half on the ground type, water pump for the self-filling-type absorbent running at the same time more reliable.
Specifications Model Description:
The series of automatic river water purifier, the integration of automatic river purification Set reaction, flocculation, sedimentation, set of mud, mud, water harvesting, water distribution, filtration, backwash, sewage and other running process the essence of one; with no personnel to operate achieve monomer automatic ability to run the water plant automation management water purification unit. Water purification plants (stations) to become a complete set of Autorun.
This series of water purification devices for integrated structure; applies not only to a wide range of treatment effect, the stability of the water quality, and water consumption, the kinetic energy consumption province, small footprint, no secondary pollution equipment to purify water. Is the integration of energy-efficient water purification of water and energy saving, saving labor, saving the project site, may merge with the clear water tank construction, and do not need to backwash the pool and auxiliary pump facilities to handle new products. Especially suitable for efficient water use areas.
Second, the performance parameters
1, applies to the raw water turbidity: ≤ 1000NTU
2, for the raw water temperature: room temperature
3, water purification water turbidity: ≤ 10NTU
4, a water effluent color: ≤ 15 (water chrominance shall not exceed 25)
5, precipitation surface load: 4.3 m3 / h? M2
6, filter design filtration rate: of 10 m / h
7, filter backwashing strength: 15 ~ 18l / s? M2 (adjustable)
8, rinse lasted: t = 1 ~ 5min (adjustable)
9, the total residence time: T total = 60 ~~ was 65 minutes
10, the device inlet pressure: ≥ 0.09MPa
Third, the performance benefits
A series of water purification equipment from the anti-reaction, flocculation and sedimentation, water harvesting, water distribution, filtering, body wash, mud run the program are to achieve the effect of the automatic operation of a central control cabinet left PLC1, on duty as long as the timing for water quality monitoring, operation and management do not need a water purification device.
2, high concentrations of flocculation layer, make the original impurities in the water particles in the meantime get full contact with the collision probability of adsorption increases, and thus can adapt to a variety of raw water temperature and turbidity, high removal efficiency of impurity particles.
3, rapid sludge concentration chamber and adjustable automatic sludge discharge system, to ensure the excess sludge is immediately removed, thus ensuring a stable impurity particle removal.
4, efficient flocculation and sedimentation effects, precipitation water quality has been maintained in good condition.
Catchment head of the catchment system and the most novel and original, so that catchment more uniform and effective, not only to improve the volume utilization factor, and the head of a very small catchment.
6, water purification systems automation, both to ensure the efficient filtering of the water purification system (in the raw water turbidity of less than 3000mg / l, the turbidity of the water after the filter can be maintained at about 3mg / l), but also automatically recoil without additional set the backwash pump or air compressor and other electrical equipment, but also save a lot of investment in infrastructure and day-to-day operation, maintenance, maintenance costs.
7, the device since the water is low about 3%, save valuable water resources play an active role.
8, small footprint, compared with the normal water structure, can save more than accounted for 50% of the ground, the height of about 2.9 m, both indoor and outdoor placement.
9, to facilitate the expansion, alteration, relocation, or ex situ and then.
10, infrastructure and short duration, for a quarter of the construction cycle of conventional clarification and filtration facilities.
11, the export of clean water height ≥ 2m, clear water tank can be built half on the ground type, water pump for the self-filling-type absorbent running at the same time more reliable.
Specifications Model Description:
|
型号规格
|
处理水量
T/H
|
进水浊度
mg/L
|
出水浊度
mg/L
|
设备尺寸
mm 长×宽×高
|
运行压力
MPa
|
|
CXJY-10型
|
10
|
3000
|
5
|
2700×1800×4650
|
＜0.1
|
|
CXJY-20型
|
20
|
3000
|
5
|
3300×2600×4650
|
＜0.1
|
|
CXJY-30型
|
30
|
3000
|
5
|
4200×2900×4650
|
＜0.1
|
|
CXJY-40型
|
40
|
3000
|
5
|
5200×3350×4650
|
＜0.1
|
|
CXJY-50型
|
50
|
3000
|
5
|
5600×3350×4650
|
＜0.1
|
|
CXJY-60型
|
60
|
3000
|
5
|
6000×3850×4650
|
＜0.1
|
|
CXJY-70型
|
70
|
3000
|
5
|
6300×4100×4650
|
＜0.1
|
|
CXJY-80型
|
80
|
3000
|
5
|
6500×4350×4650
|
＜0.1
|
|
CXJY-90型
|
90
|
3000
|
5
|
7100×4550×4650
|
＜0.1
|
|
CXJY-100型
|
100
|
3000
|
5
|
7500×4700×4650
|
＜0.1
|
|
CXJY-150型
|
150
|
3000
|
5
|
9600×5600×4650
|
＜0.1
|
|
CXJY-200型
|
200
|
3000
|
5
|
11000×5600×4650
|
＜0.1
|
